Temperature Controlled Transportation
J TEMP°
Ideal transportation service for shipments requiring
refrigeration such as fresh foods and chemicals.
We maintain the temperature at your needs with special containers.
We always have a solution
Wide range of equipments to meet your specific needs.
Temperature settings are adjustable in increments of 1℃.
We can offer the ideal solution from our various equipments to match your instructions.
Select the range of temperature to know the feature of equipment that will meet your expectations
Electric type (active)
-
- Rechargeable container
Csafe RKN - volume
Specification
- Rechargeable container
-
- Rechargeable container
RKN e1 - volume
- Specification
- Rechargeable container
-
- Rechargeable container
RAP e2 - volume
- Specification
- Rechargeable container
Dry Ice type (active)
-
- Cool container
VRR RKN - volume
- Specification
- Cool container
-
- Cool container
RKN t2 - volume
- Specification
- Cool container
-
- Cool container
VRR RAP - volume
- Specification
- Cool container
-
- Cool container
RAP t2 - volume
- Specification
- Cool container
Coolant type (passive)
-
- Passive box
va-Q-one - volume
- Specification
- Passive box
-
- Passive container
va-Q-case - volume
- Specification
- Passive container
-
- Passive container
JAL CC5 - volume
- Specification
Watch a video (English)- Watch a video (Chinese)
- Passive container
-
- Passive container
JAL CC20 - volume
- Specification
- Watch a video (English)
- Watch a video (Chinese)
- Passive container
-
- Passive container
va-Q-tainer - volume
- Specification
- Passive container
Cover type (passive)
-
- Thermal Blanket
- volume
- Specification
-
- Specail Cover
- volume
- Specification
Reefer container types
Electric type (active)
A thermostat and battery installed type of container for both Heat and Cool.
With the electricity charged at aboveground facility, the container provides strict temperature control while transportation.
- *available for plus temperature
Dry Ice type (active)
The electric fan powered by batteries will rotate dry-ice-cooled air through the container. This is the only type which can provide "freezer" transportation.
Coolant type (passive)
Maintains the temperature by using the Heat absorbing/radiation effect of Phase Change Material.
Since it does not use electricity, there are no risks for breakdown as long as the coolants keeps its effectiveness.
JAL original container (CC5,CC20) is this type of solution!
Cover type (passive)
A thermal cover using heat insulation material.
Prevents becoming frozen or over heated, and provides easy and reasonable service at normal temperatures.
- *active... often powered by electricity and/or battery to control the temperature
- *passive...often using gel packs or other types of phase change materials in order to maintain the desired temperature.
Essential temperature range especially
+2℃ to +8℃
Essential temperature range especially for pharmaceuticals.
JALCARGO offers the ideal solution from our various equipments to match your demands.
RKN e1
Heat & Cold type air freight container.
Provides strict temperature control which maintains its internal temperature at a constant level.
- *available for plus temperature
| Adjustable temperature | 0℃ to +20℃ |
|---|---|
| Loading space | 1340×1319×1315mm |
| Temperature Tolerance |
|
| Acceptable ambient temperature | −10℃ to +30℃ |
| Hours | maximum 100 hours(depends on ambient temperature) |
Csafe RKN
Heat & Cold type air freight container.
Provides strict temperature control which maintains its internal temperature at a constant level.
Internal temperature data can be provided after the transportaion.
- *available for plus temperature
| Adjustable temperature | +4℃ to +25℃ |
|---|---|
| Loading space | 1219×1273×1278mm |
| Temperature Tolerance | ±2℃ from settings |
| Acceptable ambient temperature | −30℃ to +49℃ |
| Hours | maximum 130 hours(depends on ambient temperature) |
RAP e2
Heat & Cold type air freight container.
Suitable for large shipments not available on RKNe1nor Csafe.
Provides strict temperature control which maintains its internal temperature at a constant level.
- *available for plus temperature
| Adjustable temperature | 0℃ to +25℃ |
|---|---|
| Loading space | 2465×2055×1260mm |
| Temperature Tolerance |
|
| Hours | maximum 100 hours(depends on ambient temperature) |
VRR RKN
Air freight container using dry ice as a refrigerant.
Most suitable for mainus temperature, but can also be set at the plus temperature (+2℃ to +8℃) for refrigerated product.
We carefully decide the amount of dry-ice case by case depending on the transportation time and ambient temperature.
| Adjustable temperature | −20℃ to +15℃ |
|---|---|
| Loading space | 1305×1380×1340mm |
| Temperature Tolerance |
|
| Hours | maximum 84 hours(depends on ambient temperature, amout of dry ice) |
RKN t2
Air freight container using dry ice as a refrigerant.
Most suitable for mainus temperature, but can also be set at the plus temperature (+2℃ to +8℃) for refrigerated product.
We carefully decide the amount of dry-ice case by case depending on the transportation time and ambient temperature.
| Adjustable temperature | −20℃ to +20℃ |
|---|---|
| Loading space | 1415×1355×1360mm |
| Temperature Tolerance |
|
| Hours | maximum 70 hours(depends on ambient temperature, amout of dry ice) |
VRR RAP
Air freight container using dry ice as a refrigerant.
Most suitable for mainus temperature, but can also be set at the plus temperature (+2℃ to +8℃) for refrigerated product.
We carefully decide the amount of dry-ice case by case depending on the transportation time and ambient temperature.
| Adjustable temperature | −20℃ to +15℃ |
|---|---|
| Loading space | 2080×2955×1456mm |
| Temperature Tolerance |
|
| Hours | maximum 84 hours(depends on ambient temperature, amout of dry ice) |
RAP t2
Air freight container using dry ice as a refrigerant.
Most suitable for mainus temperature, but can also be set at the plus temperature (+2℃ to +8℃) for refrigerated product.
We carefully decide the amount of dry-ice case by case depending on the transportation time and ambient temperature.
| Adjustable temperature | −20℃ to +20℃ |
|---|---|
| Loading space | 2535×2065×1420mm |
| Temperature Tolerance |
|
| Hours | maximum 70 hours(depends on ambient temperature, amout of dry ice) |
va-Q-one
Adisposable refrigerated box made by cardboard.
efficient for smaller size shipments with minimum costs.
| Adjustable temperature |
|
|---|---|
| Loading space |
|
| Hours |
over 96 hours
|
va-Q-case
Intended for small size shipments
- *available for plus and minus temperature
| Adjustable temperature | −60℃ to +25℃ |
|---|---|
| Loading space | 605x340x470mm |
| Hours |
over 120 hours
|
va-Q-tainer
The va-Q-tainers are available in various sizes and various temperature ranges.
By changing the coolant, we provide constant internal temperature control according to your specifications.
| Adjustable temperature | −60℃ to +25℃ |
|---|---|
| Loading space |
|
| Hours |
over 120 hours
|
JAL CC5
Our JAL original container equipped with GPS, shock recorder and temperature logger.
A revolutionary container which you can follow the locaton of it in real time (except during flight and certain transport sectors).
With the special coolant(+5℃type) and powerful vaccum insulator, we provide temperature control which will not be effected by ambiet temperature.
| Adjustable temperature | +2℃ to +8℃ |
|---|---|
| Loading space | 1250×1183×1086mm |
| Acceptable ambient temperature | −10℃ to +40℃ |
| Hours | maximum over 200 hours (depends on ambient temperature) |
| Loadable weight | 1,000kg |
JAL CC20
Our JAL original container equipped with GPS, shock recorder and temperature logger.
A revolutionary container which you can follow the locaton of it in real time (except during flight and certain transport sectors).
With the special coolant(+20℃type) and powerful vaccum insulator, we provide temperature control which will not be effected by ambiet temperature.
| Adjustable temperature | +15℃ to +25℃ |
|---|---|
| Loading space | 1250×1183×1086mm |
| Acceptable ambient temperature | −10℃ to +40℃ |
| Hours | over 130 hours (depends on ambient temperature) |
| Loadable weight | 1,000kg |
Thermal Blanket
A blanket-shaped thermal cover using heat insulation material.
Prevents becoming frozen or over heated, and provides simple and reasonable service at normal temperatures.
| Adjustable temperature | Prevents sudden temperature changes caused by the weather |
|---|---|
| Loading space | 310×235×151cm |
| Temperature Tolerance | normal temperature |
Specail Cover
A thermal cover using nonwoven fabric made of 100% High Density Polyethylene (HDPE)
Reduces sudden temperature fluctuations caused by solar radiation.
It also has water proof and is effective for prevention of condensation and wet damage.
| Adjustable temperature | Reduces sudden temperature fluctuations caused by solar radiation |
|---|---|
| Loading space | 292×200×162cm |
| Temperature Tolerance | normal temperature |
Applicable Commodity
| Applicable Commodity | Chemicals, Perishables(meat, fresh fish, ice cream, dough) etc. |
|---|---|
| Items Not Acceptable | Dangerous goods acceptable on Cargo Aircraft Only |
| Limitations for weight/size | Limited to weight and size that can be loaded in reefer containers |
| Temperature Range | In various temperature ranges, according to your needs. |
Freight Charge
| Freight Charge | JAL published rates (or IATA rates) |
|---|
Service available airports
| JAPAN | Tokyo(Narita, Haneda), Osaka(Kansai), Nagoya(Chubu), Fukuoka, Sapporo, Okinawa(Naha) and other online airports |
|---|---|
| AMERICA | New York, Boston, Chicago, Dallas, San Francisco, Los Angeles, Honolulu, Vancouver |
| EUROPE | London, Paris, Frankfurt, |
| EAST ASIA | Shanghai(Pudong), Beijing, Tianjin, Dalian, Hong Kong, Taipei(Taoyuan), Seoul(Gimpo, Incheon) |
| SOUTH EAST ASIA / INDIA | Singapore, Kuala Lumpur, Bangkok, Jakarta, Manila |
| GUAM / OCEANIA | Sydney, Melbourne |
Flow of Transportation
Reservation
From Japan: Up to three business days (except Sat, Sun and holidays) prior to scheduled flight departure time
From overseas: Up to five business days (except Sat, Sun and holidays) prior to scheduled flight departure time
Please let us know your desired transportation temperature, carry-in and delivery time, etc.
*Preparation of Air Waybill (AWB)
Please use JAL (131-) AWB.
Please print "J TEMP°" in the handling information column.
Acceptance
120 minutes prior to scheduled flight departure.
Delivery
Ready for AWB/other documents pick up, and customs declaration within 120 to 180 minutes after flight arrival.
- *The cargo delivery time may differ at some airports depending on business hours of Customs Offices.
- *The cut-off time for the cargo acceptance and the delivery time may depend each airport's service standard.
JALCARGO Tracing Mail Service (JTMS)
FAQ
- What would be the temperature, humidity conditions during flight?
- Generally, temperatures vary depending on the types of aircraft or the loading position, but it is possible to maintain the temperature around 20℃ (or 68F) with conditioned air.
Humidity can not be controlled during flight.
Air pressure will be decreased to around 0.8 atm during flight. - What are the applicable routes and schedule?
- You can check at the page of "Flight Timetable".
- Whom should I contact?
-
You can check at the page of Sales and Airport Offices.
